Aima

Aima Big Sur 26" Electric Bike E-Bike

Aima Big Sur 26" Electric Bike E-Bike

Regular price $1,999.00 USD
Regular price $2,399.00 USD Sale price $1,999.00 USD
Sale Sold out
Shipping calculated at checkout.
Color
Size
Product Details

Big Sur is a 26 x 4” fat tire all-terrain e-bike, equipped with a powerful 750W Bafang rear hub motor. A specially-designed big headlight, extra-large 203mm brake rotors, LG 21700 battery cells, and a full UL2849 certification make Big Sur one of the safest e-bikes on the market. Sporting a bigger 52T crankset for stability at speed and a custom AIMA Comfort XL seat, Big Sur provides riders with a remarkably comfortable and smooth riding experience.

Technical Specifications

Technical Specifications

MODEL

Big Sur

MOTOR

750W, 48V Brushless Rear Hub Motor

THROTTLE

Throttle on Demand

DISPLAY

Color LCD, Smart Easy-to-Read Display with Backlight

SPEED

Up to 20 MPH Pedal Assist, 20 MPH Throttle

BATTERY

Removable Internal Lithium-ion 48V, 15Ah (720Wh) with LG M50LT 21700 cells

REAR RACK

MIK HD

SENSOR

Torque Sensor

PEDAL ASSIST

5 PAS Levels

CHARGER

48V 3 Amp Fast Charger, about 5 Hours to a Full Charge

RANGE

30 to 60 Miles

FRAME

6061 Single-Butted Aluminum Alloy Frame with Internal Battery

WEIGHT

82 lbs. (Battery included)

PEDALS

9/16" Alloy Platform

FORK

Suspension Fork, 80mm travel, lockout

WEIGHT LIMIT

400 lbs.

KICKSTAND

Aluminum Alloy Kickstand

CRANKSET

170mm w/ 52T Chainring

SHIFTER

Shimano 8 Speed

CASSETTE

8 Speed, 11-34T

BRAKES

Tektro Hydraulic Disc Brakes, 203 mm Rotors

CHAIN

130 Link, 8 Speed

RIM

Double Wall Aluminum Alloy

SPOKES

Black Stainless 12G Front / 12G Rear

TUBES

Butyl Rubber

HUBS

Front Aluminum Alloy Disc Hub

TIRES

26" x 4" Puncture Resistant

SADDLE

AIMA Comfort, 280mm*270mm Saddle

SEATPOST

Aluminum Alloy, 30.4mm 2-Bolt Clamp

STEM

Threadless, 31.8mm, 7° Rise, 75mm Length

SEAT CLAMP

34.9mm Quick Release

HANDLEBARS

Aluminum Alloy Double Wall, 31.8mm, 680mm

HEADSET

Sealed Bearing Headset

GRIPS

Ergonomic Comfort

Exclusively available for purchase at an Authorized AIMA Dealer

Hub Motor and Battery

Powered by a 48V 15Ah battery using LG high-capacity cells, Big Sur's 750W Bafang rear hub motor has the juice to take you just about anywhere.

Torque Sensor

One of the latest e-bike innovations, a torque sensor sees how hard you pedal in real time and matches your input power using the motor. This leads to a safer and more intuitive ride, as well as conserving battery life.

Full Color Backlit LCD Display

View essential stats at any time with a bright and daylight-ready full color screen. Choose between several different themes to see your speed, battery life, pedal assist level, and much more.

26” x 4” Fat Tire

Big Sur's puncture-resistant 26" x 4" tires can handle almost any terrain, giving you the confidence you need to push your own riding limits off-road.

Suspension Fork

With up to 80mm of travel and adjustable preload and lockout settings, our suspension fork eats up everything in your path, assisted by Big Sur's 4" wide tires.

Fender & Rear Rack

An MIK HD rear rack comes standard, allowing for endless customization possibilities. Plus, fenders come pre-installed to ensure you're protected from below while riding in any weather conditions.

Flat Position Welding

We've taken great care and utilized some of the newest aluminum welding techniques available on our frame, which comes with a lifetime warranty. These techniques allow the frame to maintain its structural rigidity while also appearing flat and smooth.

Walk Assist

Walk your bike alongside you, up a hill, or anywhere you need to with Walk Assist, which allows the bike to maintain a constant ~2-3mph based on your walking speed.

Controller Compartment

Big Sur's controller is mounted right near the pedals, allowing for easy access during repairs and maintenance. Plus, this mounting style allows the controller to utilize the entire frame as a heat sink, greatly improving safety and performance under load.

NOTE FROM VELOBAZAAR: When we ship your E-Bike to you, some assembly are required and we are not responsible for the cost of adjusting the brakes/shifting/torque of every bolts and screws. Most of the assembly is pretty simple but some might found it challenging if not dealing with bicycle on regular basis.  If you need help build and assembling this bike, please hire a bicycle shop at your own cost. Thank you for your understanding.
