Marin Stinson 1 27.5 Black Charcoal Hybrid Bike

Marin Stinson 1 27.5 Black Charcoal Hybrid Bike

$499.99 USD
$599.99 USD $499.99 USD
Sale Sold out
Shipping calculated at checkout.
Color
Size

CASUAL FITNESS

The Stinson is an updated take on the classic cruiser design for casual and comfortable path riding. Comfort Control Geometry allows riders to touch the ground with their foot for confident and safe riding and stopping.

Specifications

  • Frame

    Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts

  • Fork

    CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets

  • Rims

    Marin Aluminum Double Wall, Disc Specific

  • Hub, Rear

    Forged Aluminum Alloy, 32H

  • Hub, Front

    Forged Aluminum Alloy, 32H

  • Spoke, Nipples

    14g Stainless Steel

  • Tires

    Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection

  • Derailleur, Rear

    Shimano Tourney, 7-Speed

  • Derailleur, Front

    -

  • Shift Lever

    Shimano Altus 7-Speed RapidFire

  • Crankset

    Alloy Crank, Steel 38T Chainring, Ring Guard

  • Bottom Bracket

    Sealed Cartridge Bearings, Square Taper

  • Chain

    KMC Z8

  • Cassette

    SunRace 7-Speed, 11-34T

  • Brake, Front

    Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor

  • Brake, Rear

    Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor

  • Brake Levers

    Shimano w/ Integrated Shifters

  • Handlebar

    Marin Alloy, 60mm Rise, 30˚ Backsweep

  • Stem

    Marin Alloy

  • Grips

    Marin County

  • Headset

    FSA, TH No.10P

  • Seatpost

    Marin Alloy, 30.9mm

  • Saddle

    Marin Comfort

  • Pedals

    Marin Comfort Platform

    Geometry

    2023 Stinson 1 geometry diagram
    S M L XL
    Stack 628.2 646.9 665.5 679.4
    Reach 340 355 370 381.6
    Headtube Angle 68.5° 68.5° 68.5° 68.5°
    Headtube Length 210 230 250 265
    Seattube Angle 67° 67° 67° 67°
    Seattube Length 382 406 444 470
    Toptube Effective 606.7 629.6 652.5 670
    BB Height 276.5 276.5 276.5 276.5
    BB Drop 68 68 68 68
    Chainstay 485 485 485 485
    Wheelbase 1083.9 1106.2 1128.6 1145.65
    Standover Height 618.44 618.48 674.72 675.89
    Fork Offset 40 40 40 40
    Seatpost Diameter 30.9 30.9 30.9 30.9
    Handlebar Width 700 700 700 700
    Stem Length 45 45 45 45
    Crank Length 170 170 170 170

    All lengths in millimeters
